HY34 Hydraulic Press for Automative parts
Characteristics:
The use of advanced electro-hydraulic control system, fast up and down capacity to reach 500mm / s, pressurized piston accumulator, built-in speed, performance, stable, using a new generation of closed-loop proportional control technology, digital display And setting position, pressure and speed;
Unified configuration of straight-in fiber extruder, glass fiber length is evenly adjustable, and no other secondary turnover process, less chance of dust pollution;
| HY34 Special hydraulic press for car interior decoration | |||||
| Items Type | Unit | HY34-100 | HY34-200 | HY34-315 | |
| Nominal Pressure | kN | 1000 | 2000 | 3150 | |
Return force | kN | 400 | 440 | 550 | |
| Size of Working Table | Left-Right | mm | 2960 | 3200 | 3200 |
| Front-Back | mm | 1800 | 2200 | 2200 | |
| T Groove | mm | 28 | 28 | 28 | |
| Opening Height | mm | 2160 | 1250 | 1250 | |
| Slider Stroke | mm | 1560 | 810 | 810 | |
| The Max. Pressure of System | Mpa | 25 | 25 | 25 | |
| Quick Descend Speed | mm | ≥300 | ≥300 | ≥300 | |
| Pressing Speed | mm/s | 15~30 | 15~30 | 15~30 | |
| Slider Return | mm/s | ≥200 | ≥200 | ≥200 | |
