HY61 Metal Hydraulic Extruding Press
Characteristics:
Computer optimized design, frame structure with small working table, High body strength, economic and practical
Cartridge Valve Integrated System equipped in hydraulic control system, with high reliability, durability, small hydraulic impact and minimizing hydraulic impact design
| HY61 Metal Hydraulic Press | ||||||||||
| Items Type | HY61-200 | HY61-315 | HY61-400 | HY61-500 | HY61-630 | HY61-800 | HY61-1000 | HY61-1250 | ||
| Nominal Pressure | kN | 2000 | 3150 | 4000 | 5000 | 6300 | 8000 | 10000 | 12500 | |
| The Max. working Pressure of Hydraulic | Mpa | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | |
| Main Cylinder Stroke | mm | 350 | 350 | 350 | 400 | 450 | 500 | 500 | 900 | |
| Stroke of Below Ejector Cylinder | mm | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 300 | |
| The Max. Opening between Slider and Working Table | mm | 600 | 600 | 650 | 700 | 800 | 850 | 850 | 1500 | |
| Active Area of Working Table | mm×mm | 580x700 | 620×700 | 720x720 | 720x800 | 800x880 | 860x920 | 860x1000 | 1300x1300 | |
| Speed of Slider | Quick Descend | mm/s | 300 | 300 | 350 | 350 | 280 | 300 | 300 | 300 |
| Slow Descend | mm/s | 12～30 | 10～25 | 10～25 | 10～25 | 10～23 | 10～22 | 10～20 | 8～24 | |
| Return | mm/s | 230 | 200 | 200 | 130 | 110 | 160 | 200 | 130 | |
The above parameters are for reference only and can be customized according to customer requirements. Our company continuously researches and improves, and any changes in specifications will not be notified separately. | ||||||||||
