Y27 Single Action Hydraulic Press
Based on Computer Optimizing Structure Design. Four-Column type Hydraulic Press is with simple structure, economic and practical; T
Cartridge Foundation System equipped in hydraulic control system and below 550t, equipped in Electro-slider valve hydraulic system with high reliability and durability, small hydraulic impact, and minimum hydraulic impact design.
Electrical system controlled by PLC unit, with the features of compact, sensitivity, reliability and flexibility.
| Items | Unite | HY27-315 | HY27-500 | HY27-630 | HY27-800 | HY27-1000 | HY27-2000 |
|---|---|---|---|---|---|---|---|
| Nominal Pressure | kN | 3150 | 5000 | 6300 | 8000 | 10000 | 20000 |
| Knock-Out Force | kN | 300 | 810 | 600 | 830 | 1300 | 2100 |
| Hydraulic Cushion Force | kN | 1500 | 2000 | 3150 | 3000 | 4000 | 8000 |
| Buffering Power | kN | / | 800*2 | 1000*2 | 1500*2 | 3000*2 | 4000*2 |
| The Max.Distance Between Working Table and Slider | mm | 1200 | 1500 | 1500 | 1600 | 2000 | 1800 |
| Slider Stroke | mm | 800 | 1000 | 1000 | 1000 | 1500 | 1300 |
| Hydraulic Cushion Strocke | mm | 300 | 300 | 300 | 400 | 400 | 400 |
| The Height Between Working Table and Ground | mm | 600 | 600 | 600 | 600 | 600 | 645 |
| Speed of Slider（Downstream） | mm/s | 300 | 300 | 350 | 300 | 400 | 350 |
| Speed of Slider（Pressing） | mm/s | 12-26 | 12-25 | 12-28 | 12-25 | 12-25 | 18-38 |
| Speed of Slider（Return） | mm/s | 280 | 280 | 300 | 300 | 300 | 300 |
| Speed of Hydraulic Cushion（Rising） | mm/s | 55 | 55 | 50 | 60 | 80 | 80 |
| Size of Working Table（Left-Right） | mm | 1500 | 2500 | 2500 | 3000 | 4000 | 4000 |
| Size of Working Table（Front-Back） | mm | 1200 | 1800 | 2000 | 1800 | 2400 | 2500 |
| Size of Hydraulic Cushion（Left-Right） | mm | 1000 | 1950 | 1800 | 2000 | 2850 | 3200 |
| Size of Hydraulic Cushion（Front-Back） | mm | 800 | 1200 | 1200 | 1100 | 1850 | 1700 |
